JET JSMS-10L-M Sliding mitre saw
Item numberJSMS-10L-M
EAN / GTIN7612375700718
343,91 € gross289,00 € netincl. VAT · Shipping costs
The JET JSMS-10L-M is a sliding compound mitre saw for wood and wood-based materials. 230 V motor with 1500 W, Ø 254 mm blade, cutting length 305 / 215 mm at 90° / 45°, with laser.
AvailableAvailable ex works
Delivery / availability: Delivery time 5–7 working days. The period starts after conclusion of the contract or, for agreed prepayment, after your payment instruction. Delivery by freight carrier to the kerbside, without installation or carrying the goods into the building or to their intended location. A telephone number is required to arrange delivery. Please refuse delivery if there is obvious transport damage and contact us. Have visible damage recorded on the consignment note. CMR is the convention governing international carriage of goods by road; for these shipments, the CMR consignment note serves as evidence of transport. Refusing delivery is not a general CMR requirement. Statutory consumer rights remain unaffected even if the goods are accepted.
Stock sourceAvailable ex works
Customer groupPurchase: businesses and private customers
In use
Overview
The JET JSMS-10L-M is a sliding compound mitre saw for interior fitting, installation work, workshops and construction sites. It is intended for sawing wood and wood-based materials, and metal must not be cut. The sliding mechanism also allows wider boards and panels to be cut to length.
The 230 V motor with an input power of 1500 W drives the 254 × 2.8 × 30 mm blade at 4500 rpm and is fitted with a brake. The cutting height is 90 / 42 mm and the cutting length 305 / 215 mm at 90° / 45°. The saw head tilts 0° – 45° to the left, and the turntable allows mitres up to 45° / 45° left / right with detents at 0° / 15° / 22.5° / 30°.
An XACTA laser indicates the cutting line, and the spindle lock makes blade changes easier. The die-cast aluminium construction keeps the weight at 18 kg. Supplied with work clamp, table extensions up to 1030 mm, length stop, dust bag and saw blade.
Features at a glance
- 230 V motor, 1500 W input power, with brake
- Sliding function, cutting length 305 / 215 mm at 90° / 45°
- Bevel 0° – 45° left, mitre 45° / 45°
- XACTA laser
- Spindle lock for blade changes
- Table extensions up to 1030 mm
Benefits
- Convenient saw blade change
- Lightweight and stable
- Individually adjustable
Technical data
| Electrical | |
|---|---|
| Voltage | 1~230 V, 50 – 60 Hz |
| Phases | 1 |
| Input power | 1500 W |
| Operating current | 6.5 A |
| Power cord | H05VV-F 2 × 1.0 mm² |
| Installation fuse | 10 A |
| Protection class | II (double insulated) |
| Capacities | |
| Saw blade (dia. × thickness × bore) | 254 × 2.8 × 30 mm |
| No-load speed | 4500 rpm |
| Max. cutting height 90° / 45° | 90 / 42 mm |
| Max. cutting length 90° / 45° | 305 / 215 mm |
| Bevel capacity left | 0° – 45° |
| Mitre capacity left / right | 45° / 45° |
| Mitre detents | 0° / 15° / 22.5° / 30° |
| Table | |
| Table extension up to | 1030 mm |
| Dust extraction | |
| Dust port | Ø 30 / 40 mm (inner / outer) |
| Dimensions | |
| Dimensions (L × W × H) | 1047 × 911 × 597 mm |
| Weight | |
| Net weight | 18 kg |
| Shipping weight | 43 kg |
| Further data | |
| Laser | class 2, max. 1 mW, 400 – 700 nm |
| Sound pressure level | LpA 88.7 dB(A) idling |
| Sound power level | LwA 101.5 dB(A) idling |
Target audience
Professional users, workshops and demanding trade businesses.
Application
For typical sliding mitre saw applications in workshops and production.
Scope of delivery
- JET JSMS-10L-M sliding mitre saw
- 1 × dust bag
- 1 × workpiece clamp
- 2 × table extension pieces (up to 1030 mm)
- 1 × length gauge
- 1 × spanner 13 mm
- 1 × saw blade
- XACTA Laser™
- Operating manual
- Spare parts list
Product safety
- Manufacturer: JPW Industries, Inc.
- Website: https://www.jettools.com/
- Distributor / service contact: Christian Satter / ToolParts-Service
- Address: Kleinhaslach 35, 90599 Dietenhofen, Deutschland
- Website: https://toolparts-group.com/
Product identifiers
- Article number: JSMS-10L-M
- MPN: JSMS-10L-M
- EAN/GTIN: 7612375700718
Technical data
Additional data
- Marke
- JET
- Product type
- Machine
- Baureihe
- JSMS-10L
- Modell/Typ
- Kapp- und Gehrungssäge
- Original/Kompatibel
- Originalprodukt
Downloads
Operating manuals and spare-parts listsProduct safety
Manufacturer
JPW Industries, Inc.427 New Sanford Rd37086 La Vergne, TNUnited StatesEU importer
Tool France SAS9 rue des Pyrénées91090 LissesFranceService & spare parts
Technical documents, spare-parts identification and repair support remain permanently available through ToolParts-Service.
Open technical service
