JET JTS-600XL-M Table saw
Item numberJTS-600XL-M
EAN / GTIN7612375537000
Watch video2.192,15 € gross1.842,14 € netincl. VAT · Shipping costs
The JET JTS-600XL-M is a panel saw for wood, wood-based materials and board stock. 230 V single-phase motor with 1.5 kW, sliding table stroke 1700 mm, cutting height 80 / 54 mm at 90° / 45°.
AvailableAvailable ex works
Delivery / availability: Delivery time 5–7 working days. The period starts after conclusion of the contract or, for agreed prepayment, after your payment instruction. Delivery by freight carrier to the kerbside, without installation or carrying the goods into the building or to their intended location. A telephone number is required to arrange delivery. Please refuse delivery if there is obvious transport damage and contact us. Have visible damage recorded on the consignment note. CMR is the convention governing international carriage of goods by road; for these shipments, the CMR consignment note serves as evidence of transport. Refusing delivery is not a general CMR requirement. Statutory consumer rights remain unaffected even if the goods are accepted.
Stock sourceAvailable ex works
Customer groupPurchase: businesses and private customers
In use
Overview
The JET JTS-600XL-M is a panel saw for joinery shops, workshops, trades and schools. It is intended for sawing wood, wood-based materials and hard plastics, and metal must not be cut. Using the sliding table, panels and workpieces up to 1600 mm long can be edged and cut to size.
The 230 V single-phase motor with 1.5 kW drives saw blades up to 250 mm diameter at 4000 rpm. The cutting height is 80 / 54 mm at 90° / 45°, and the blade tilts within 90° – 45°. Ripping widths up to 610 mm are possible at the rip fence. Height and tilt are set with large cast iron handwheels.
The precision-ground cast iron table measures 800 × 350 mm. The sliding table made of extruded, anodised aluminium has a stroke of 1700 mm, and the rip fence with micro-adjustment runs on a round bar. Supplied with stand, sliding table 1600 × 240 mm, two support legs, outrigger table 460 × 600 mm with crosscut fence extendable to 2200 mm, table extension, rear table extension, rip fence, blade guard, a saw blade and the dust port.
Features at a glance
- 230 V single-phase motor, 1.5 kW
- Cutting height 80 / 54 mm at 90° / 45°
- Cast iron table 800 × 350 mm
- Sliding table 1600 × 240 mm, stroke 1700 mm
- Outrigger table 460 × 600 mm with crosscut fence
- Rip fence with micro-adjustment
Benefits
- Surface-ground cast-iron table
- Heavy-duty sliding table: Made from anodized extruded aluminium profile (1,600 mm) for optimum stability and long service life.
- User-friendly operation
- Outrigger table for more flexibility
Technical data
| Electrical | |
|---|---|
| Voltage | 230 V ~1/N/PE, 50 Hz |
| Phases | 1 |
| Motor output S1 | 1.5 kW (2 PS) |
| Operating current | 11.0 A |
| Power cord | H07RN-F 3 × 1.5 mm² |
| Installation fuse | 16 A |
| Protection class | B |
| Capacities | |
| Saw blade diameter | max. 250 mm |
| Blade bore | 30 mm |
| Blade speed | 4000 rpm |
| Cutting height at 90° / 45° | 80 / 54 mm |
| Blade tilt | 90° – 45° |
| Max. width of rip cut | 610 mm |
| Max. length of cut | 1600 mm |
| Table | |
| Machine table | 800 × 350 mm |
| Right extension table | 800 × 270 mm |
| Rear extension table | 415 × 350 mm |
| Sliding table | 1600 × 240 mm |
| Max. travel of sliding table | 1700 mm |
| Crosscut table | 460 × 600 mm |
| Dust extraction | |
| Dust port | Ø 100 mm |
| Minimum air volume | 565 m³/h (at 20 m/s, 850 Pa) |
| Dimensions | |
| Dimensions (L × W × H) | 1650 × 2200 × 1100 mm |
| Weight | |
| Net weight | 170 kg |
| Shipping weight | 195 kg |
| Further data | |
| Sound pressure level | LpA 84.2 dB(A) idling / 88.5 dB(A) operating |
| Sound power level | LwA 98.2 dB(A) idling / 101.8 dB(A) operating |
Target audience
Professional users, workshops and demanding trade businesses.
Application
For typical table saw applications in workshops and production.
Scope of delivery
- JET JTS-600XL-M sliding table saw
- Machine stand
- Sliding table 1600 × 240 mm
- 2 × sliding table support legs
- Crosscut table 460 × 600 mm
- Crosscut fence extendable to 2200 mm
- Telescopic arm
- Rear extension table
- Right extension table
- Rip fence with dual fence profile
- Rip fence support bar
- Saw guard
- Saw blade Ø 254 × 30 × 3 mm, 36 alternate teeth
- Dust connection hose and Y-adapter
- Dust port Ø 100 mm
- Hose clamp
- Push stick
- Operating tools
- Assembly bag
- Operating manual
- Spare parts list
Product safety
- Manufacturer: JPW Industries, Inc.
- Website: https://www.jettools.com/
- Distributor / service contact: Christian Satter / ToolParts-Service
- Address: Kleinhaslach 35, 90599 Dietenhofen, Deutschland
- Website: https://toolparts-group.com/
Product identifiers
- Article number: JTS-600XL-M
- MPN: JTS-600XL-M
- EAN/GTIN: 7612375537000
