JET JWDS-1632-M open-ended drum sander
Item numberJWDS-1632-M
Watch video1.469,00 € gross1.234,45 € netincl. VAT · Shipping costs
Open-ended drum sander for workpieces up to 406 mm wide in one pass and up to 812 mm in two passes.
AvailableAvailable ex works
Delivery / availability: Delivery time 5–7 working days. The period starts after conclusion of the contract or, for agreed prepayment, after your payment instruction. Delivery by freight carrier to the kerbside, without installation or carrying the goods into the building or to their intended location. A telephone number is required to arrange delivery. Please refuse delivery if there is obvious transport damage and contact us. Have visible damage recorded on the consignment note. CMR is the convention governing international carriage of goods by road; for these shipments, the CMR consignment note serves as evidence of transport. Refusing delivery is not a general CMR requirement. Statutory consumer rights remain unaffected even if the goods are accepted.
Stock sourceAvailable ex works
Customer groupPurchase: businesses and private customers
In use
Sanding strip cutting template
Cutting drawing for the sanding strip of this machine – click the preview to enlarge, download the PDF to print.
All drawings: © ToolParts-Group. Check the dimensions on your own machine before cutting.
Overview
The JET JWDS-1632-M combines a precision aluminium sanding drum with variable feed. Sandsmart monitors load to support consistent material removal. Its open-ended design allows wider workpieces to be processed in two passes.
Benefits
- Open-ended design
- Sandsmart feed control
- variable feed
- precision aluminium drum
- sealed and permanently lubricated bearings.
Technical data
230 V, single phase, 50 Hz; P1 1.6 kW; 127 × 410 mm drum; 0–3 m/min feed; 406/812 mm sanding width.
Target audience
Professional and demanding woodworkers.
Application
Dry sanding of wood and wood-like materials.
Scope of delivery
- Machine, open stand with shelf, installed 80-grit abrasive, installed 100-grit conveyor belt, elevation handwheel, manual and parts list.
Not included
- Dust extractor and optional table extensions.
Product safety
- Manufacturer: JPW Industries, Inc.
- Website: https://www.jettools.com/
- Distributor / service contact: Christian Satter / ToolParts-Service
- Address: Kleinhaslach 35, 90599 Dietenhofen, Deutschland
- Website: https://toolparts-group.com/
Product identifiers
- Article number: JWDS-1632-M
- MPN: JWDS-1632-M
- EAN/GTIN: 7612375526400
@ToolPartsGroup
Visit our YouTube channel
Product video
JET JWDS-1632-M – Dein Projekt, unser Know-how | ToolParts-Group
Technical data
Additional data
- Brand
- JET
- Product type
- Machine
- Series
- JWDS
- Model/type
- Zylinderschleifmaschine in offener Bauweise
- Voltage
- 230 V
- Frequency
- 50 Hz
- Original/compatible
- Original product
- Net weight
- 71 kg
- Sanding width, one pass
- 406 mm
Electrical data
- Phases
- 1
- Motor power S1 (continuous duty)
- 1,1 kW
- Motor power S6 (intermittent duty)
- 1,6 kW
Downloads
Operating manual JWDS-1632-M (PDF, DE/EN/FR) · Edition 2017-01
Operating manuals and spare-parts listsProduct safety
Manufacturer
JPW Industries, Inc.427 New Sanford Rd37086 La Vergne, TNUnited StatesEU importer
Tool France SAS9 rue des Pyrénées91090 LissesFranceService & spare parts
Technical documents, spare-parts identification and repair support remain permanently available through ToolParts-Service.
