TOOL FRANCE TFD-16 Bench Drill Press
Item numberTFD-16
332,01 € gross279,00 € netincl. VAT · Shipping costs
The Tool France TFD-16 is a bench drill with 230 V motor and 12 speeds from 200 – 2500 rpm. It drills up to 16 mm and weighs 30 kg.
AvailableAvailable ex works
Delivery / availability: Delivery time 5–7 working days. The period starts after conclusion of the contract or, for agreed prepayment, after your payment instruction. Delivery by freight carrier to the kerbside, without installation or carrying the goods into the building or to their intended location. A telephone number is required to arrange delivery. Please refuse delivery if there is obvious transport damage and contact us. Have visible damage recorded on the consignment note. CMR is the convention governing international carriage of goods by road; for these shipments, the CMR consignment note serves as evidence of transport. Refusing delivery is not a general CMR requirement. Statutory consumer rights remain unaffected even if the goods are accepted.
Stock sourceAvailable ex works
Customer groupPurchase: businesses and private customers
In use
Overview
The Tool France TFD-16 is a bench drill for workshops, trades and schools. The 230 V motor with 0.4 kW drives the ball-bearing spindle via V-belts, with 12 speeds from 200 to 2500 rpm. Drilling capacity is max. 16 mm, the spindle taper is MT2 and the stroke 65 mm.
The cast steel column measures Ø 60 mm. The table is height-adjusted by rack and pinion and tilts up to 45°. The ON/OFF switch has a no-voltage release, and an emergency stop button is fitted. The pulley cover has a safety microswitch and the chuck guard is interlocked.
Supplied are a keyless chuck 1 – 16 mm (B18), chuck arbor, drift key and service keys. A vice is available as an accessory. The machine measures 500 × 260 × 830 mm and weighs 30 kg.
Features at a glance
- Drilling capacity max. 16 mm, MT2 spindle
- 12 speeds 200 – 2500 rpm
- Rack-and-pinion table, tilts up to 45°
- No-voltage release and emergency stop
- Interlocked chuck guard
- Keyless chuck 1 – 16 mm included
Benefits
- Twelve spindle speeds • Worktable tilts to 45° • 16 mm keyless chuck
Technical data
Electrical data
- Voltage
- 230 V, 50 Hz
- Phases
- 1
- Motor output
- 0.4 kW
- Current
- 1.74 A
Machining data
- Drilling capacity
- max. 16 mm
- Spindle taper
- MT2
- Spindle stroke
- 65 mm
- Number of speeds
- 12
- Speed range
- 200 – 2500 rpm
- Column diameter
- Ø 60 mm
- Throat (spindle to column)
- 170 mm
- Quill diameter
- Ø 40 mm
- Spindle to table distance
- max. 300 mm
- Spindle to base distance
- 430 mm
Table
- Table size
- 210 × 205 mm
- T-slots
- 12 mm
- Table tilt
- up to 45°
Dimensions
- Dimensions (D × W × H)
- 500 × 260 × 830 mm
Weight
- Net weight
- 30 kg
Additional data
- Sound pressure level
- LpA 63.4 dB(A)
- Sound power level
- LwA 76.4 dB(A)
Delivery & scope of delivery
Scope of delivery
- TOOL FRANCE TFD-16 bench drill
- Keyless chuck 1 – 16 mm (B18)
- Chuck arbor
- Drift key
- Service keys
Downloads
Operating manuals and spare-parts listsProduct safety
WARNING: Entanglement, crushing and cutting hazards from rotating tools and unsecured workpieces. Clamp the workpiece securely and disconnect the machine from the power supply before changing the chuck or tool.
Product safety – TOOL FRANCE TFD-16 Bench Drill Press. Use only for its intended purpose and within the limits specified in the original operating instructions. Operation is restricted to trained adults. Before each use, inspect the machine, guards, controls and power connection; do not operate damaged or incomplete equipment. Ensure stable installation, a clear and well-lit work area and the power supply stated on the rating plate. Before adjustment, cleaning or maintenance, switch off, disconnect the machine from the power supply and wait until all movement has stopped. Wear close-fitting clothing and suitable eye and hearing protection; remove jewellery and secure long hair. Never remove or bypass guards. Always secure workpieces with a vice or suitable clamps. Remove chuck keys before starting, keep hands away from the spindle and tool, and remove swarf only after the machine has stopped using a suitable tool.
Manufacturer
Tool France SAS9 rue des Pyrénées91090 LissesFranceEU economic operator
Tool France SAS9 rue des Pyrénées91090 LissesFranceService & spare parts
Technical documents, spare-parts identification and repair support remain permanently available through ToolParts-Service.
