JET JWBS-15-M Band saw
Item numberJWBS-15-M
EAN / GTIN7612375520453
2.338,05 € gross1.964,75 € netincl. VAT · Shipping costs
The JET JWBS-15-M is a band saw for wood, wood-based materials and plastics. 230 V single-phase motor with 1.1 kW, cutting height 356 mm and cutting width 360 mm.
AvailableAvailable ex works
Delivery / availability: Delivery time 5–7 working days. The period starts after conclusion of the contract or, for agreed prepayment, after your payment instruction. Delivery by freight carrier to the kerbside, without installation or carrying the goods into the building or to their intended location. A telephone number is required to arrange delivery. Please refuse delivery if there is obvious transport damage and contact us. Have visible damage recorded on the consignment note. CMR is the convention governing international carriage of goods by road; for these shipments, the CMR consignment note serves as evidence of transport. Refusing delivery is not a general CMR requirement. Statutory consumer rights remain unaffected even if the goods are accepted.
Stock sourceAvailable ex works
Customer groupPurchase: businesses and private customers
In use
Overview
Discover the perfect combination of power, precision and user-friendliness with our high-quality wood bandsaw. Whether you are a professional carpenter, enthusiastic DIY user or wood lover, this tool will take your work to the next level. Maximum cutting capacity and versatility Rely on quality that pays off - experience how this wood bandsaw transforms your projects. Find out more now and invest in top performance!
Benefits
- Robust cast-iron table (546 × 406 mm): Precision-ground for maximum stability and perfect workpiece support - even on
- Quick-release and tensioning system: Makes changing and tensioning the saw blade easier for time-saving work.
- Electromechanical motor brake: Ensures maximum safety and controlled operation.
- Tool-free adjustable ball-bearing guide: Adjust the saw blade guide precisely and effortlessly - for smooth cuts.
- Cast table trunnion: Even more stability and perfect support for larger workpieces.
- Viewing window: Keep an eye on blade tracking at all times and make simple adjustments.
- 356 mm cutting height: Ideal for sawing large pieces of wood, cutting veneers or cutting stacked material.
- Precise rip fence: With integrated fine adjustment and robust round-bar guide for maximum accuracy.
- Rack-and-pinion adjustment: The upper saw blade guide can be adjusted conveniently with a handwheel - fast and precise.
- Solid guide column: Provides optimum support for the saw blade, even during demanding cuts.
Technical data
| Electrical | |
|---|---|
| Voltage | 230 V, PE, 50 Hz |
| Phases | 1 |
| Output power S1 | 1.1 kW (1.5 HP) |
| Operating current | 6 A |
| Power cord | H07RN-F 3 × 1.5 mm² |
| Installation fuse | 16 A |
| Protection class | I |
| Capacities | |
| Wheel diameter | 375 mm |
| Max. cutting width | 360 mm |
| Max. cutting height | 356 mm |
| Saw blade length | 3380 mm (3350 – 3390 mm) |
| Blade width | 3 – 25 mm |
| Blade thickness | 0.5 – 0.7 mm |
| Cutting speed | 760 m/min |
| Table | |
| Table size (L × W) | 545 × 405 mm |
| Table tilt | -5° to 45° |
| Working height | 890 mm |
| Dust extraction | |
| Dust port | 2 × Ø 100 mm |
| Minimum air volume | 565 m³/h (at 20 m/s, 1250 Pa) |
| Dimensions | |
| Dimensions (W × D × H) | 750 × 810 × 1880 mm |
| Weight | |
| Net weight | 172 kg |
| Shipping weight | 197 kg |
| Further data | |
| Sound pressure level | LpA 74 dB(A) idling / 87 dB(A) operating |
| Sound power level | LwA 82 dB(A) idling / 93 dB(A) operating |
Target audience
Professional users, workshops and demanding trade businesses.
Application
For typical band saw applications in workshops and production.
Scope of delivery
- JET JWBS-15-M band saw
- Rip fence (fence body and fence profile) with guide rail
- Table with table insert
- Mitre gauge ± 45°
- Lifting ring
- Hand wheel with handle
- Saw blade 13 mm
- Dust port Ø 100 mm
- Hardware package (screws, washers, table slot handle assembly)
- Operating manual
- Spare parts list
Product safety
- Manufacturer: JPW Industries, Inc.
- Website: https://www.jettools.com/
- Distributor / service contact: Christian Satter / ToolParts-Service
- Address: Kleinhaslach 35, 90599 Dietenhofen, Deutschland
- Website: https://toolparts-group.com/
Product identifiers
- Article number: JWBS-15-M
- MPN: JWBS-15-M
- EAN/GTIN: 7612375520453
